EtchON Desktop CO2 Laser Marking Machine CLM201

About EtchON Desktop CO2 Laser Marking Machine CLM201

• EtchON CLM201, is an Export series desktop table type Co2 laser marking machine with 30W Laser source and can be upgraded to 40W and 60W as per the requirement.Co2 Non-metal laser marking, and engraving machine is a gas laser machine whose frequency band wavelength of infrared light is 1060um and widely used for marking and engraving on Non-metals.

•  Laser Source Type:JPT/eARCIS(30W/40W/60W)

   Galvo Scan Head:Imported Galvonometer eVaayu Galvo/SINO Galvo

   Control System:EzCad(PC Based) /FLECAD(No need of separate PC)

• Product Details:

• Cooling	Air Cooling
  Frequency of Pluse	20-80 kHz
  Laser Generator Life	50000-100000 Hours
  Marking Speed	10000 mm/s
  Mini Line Characters	0.15 mm
  Mini Line Width	0.02 mm
  Operation Temperature	10-40  Degree C.
  Optional Marking Area	150 mm x 150 mm,200 mm x 200 mm
  Respected Precision	0.001 mm
  Software	EZCAD (PC Required)/FLECAD (Standalone)
  Brand	EtchON
  Power Supply	220 VAC +/- 10 % 50 Hz or 110 VAC +/- 10 % 60 Hz
  Laser Type	CO2 Laser
  Model	CLM201
